New Apache Module Injection

For the last few months we have been talking about the Darkleech Apache Module injection that is being used to insert malicious iframes into every site hosted on a compromised Linux server.

However, this past week we detected a new type of Apache module injection that is more subtle and increasingly difficult to detect. We don’t know if it is a new and improved version of Darkleech or a completely different tool written by a different group. Our team is still working on the binary and trying to scope the reach of this infection, so we will only post our preliminary analysis here.

Identifying the injection

The first sign of this injection can be identified remotely by an iframe injection like this one:

<iframe src=httpx://ajaxfamilies[.]org/go[.]php?sid=3 width=1 ..

That gets randomly prepended at the top of the pages loaded from the compromised server. That injection is conditional, so depending on the browser, referrer or IP address it may not show up. Google also says that 500+ sites have been distributing malware through this domain (

Has this site acted as an intermediary resulting in further distribution of malware? Over the past 90 days, appeared to function as an intermediary for the infection of 562 site(s) including,,

Note that the domain might not be the only one being used (and it might change or rotate soon). However, from the servers we were able to gain access to, it was the main domain being used.

Apache Module injection

The injection is being done in the same way was before, by modifying one of the httpd configuration files (either conf/httpd.conf or conf.d/*.conf) and inserting a new module to be loaded:

LoadModule suphp5_module modules/

Note that mod_suphp5 is a false module and not the popular mod_suphp one. We have also seeing it injected by overwriting the default with a fake one:

LoadModule version_module modules/

Those new modules are very small in size and have 0 detection rate by common anti virus software, according to virus total.

This is their identifier (size and md5 checksum):

$ ls -la *.so
-rwxr-xr-x 1 dcid dcid 15472 19 Jun 14:03
-rw-r–r– 1 dcid dcid 15472 17 Jun 18:53
$ md5 *.so
MD5 ( = 0a64f8d809d0a73d1b0b4139126e8f94
MD5 ( = 71e800af61521ff4390bf9845befa33a

It uses Apache’s portable memory pool to store the list of IP addresses that visited the site before and to decide when to inject the malware. It also has a backdoor part of it, allowing the remote attacker to run any command as the user Apache.

This module has some unique signatures that you can use to search for it. At this point we recommend looking for AWAVAUATUS1 on the modules directory:

$ grep -r AWAVAUATUS1 /etc/httpd/modules
Binary file /etc/httpd/modules/ matches

You can also search for execl or getppid on the module directory and see if any suspicious file comes up. On the default Apache/PHP install, only libphp5 would have a call for execl or getppid on it.

If you suspect a site might be compromised, our sitecheck scanner should be able to identify this type of injection.

What’s next?

It seems the switch from site-level injections to server-level injections is really here to stay. If you don’t know how an attacker with just basic FTP or restricted access can get root, take a look at this series of posts we are doing:

We will also provide more information as we learn more about it.
